video image, high-speed interfaces, ddr, pcie, communication infrastructure

product brief

ph1a series fpga products are one of the "phoenix" series launched by anlogic infotech. the product offers 60-180k luts, high-speed serial i/os, pcie hardcores, ddr3/ddr4 memory interfaces and rich ip resources, positioned in the cost-effective programmable logic market; ph1a provides best-in-class transceiver and signal processing functions while maintaining low power consumption. ph1a is capable of meeting the size-, weight-, power- and cost-sensitive markets such as communication infrastructure, and medical, industrial and consumer electronics, providing developers with a better solution.


contact sales

product table

find 7 results
device luts dffs distributeram eram-20k eram-total dsp pll serdes-channels serdes-rate ddr-rate ddr-width mipi-io user io package methods package size sphere pitch
210240 233600 3300k 646 12920k 600 16 8 12.5gbps 1866mbps x72 20 396 fcbga676 27*27 1.0mm
115776 128640 1680k 272 5440k 240 12 8 6.25gbps 1066mbps x16 - 148 lfbga324 15*15 0.8mm
115776 128640 1680k 272 5440k 240 12 4 12.5gbps 1066mbps x40 20 280 lfbga484 23*23 1.0mm
70848 78720 780k 158 3160k 120 12 - - - - - 211 lfbga324 15*15 0.8mm
115776 128640 1680k 272 5440k 240 12 4 6.25gbps 1066mbps x40 20 180 lfbga325 15*15 0.8mm
417024 463360 5500k 914 18280k 840 20 8 12.5gbps 1866mbps x72 \ 400 fcbga676 27*27 1.0mm
417024 463360 5500k 914 18280k 840 20 16 12.5gbps 1866mbps x72 \ 500 fcbga900 31*31 1.0mm
  • product features
  • application scenarios
  • materials download

product features

  • high-performance, high-capacity configurable logic modules

    logic scales from 70,848 to 210,240 luts

  • high-performance digital signal processing unit

    support two-input adders, three-input adders, multipliers, and arithmetic logic units

  • high performance serial transceivers

    support up to 12.5 gbps channel rate and multiple protocols

  • integrated pcie hardcores

    support gen1/2/3, and x1/x2/x4 modes

  • support ddr3 and ddr4 storage interface

    support up to 1866 mbps, x8/x16/x32/x64 bit width

  • seu error checking and error correction

    support single-bit error detection and error correction, and support double-bit error detection

  • dedicated mipi-io

    support 2.5 gbps, and csi-rx
